    R6160 Diesel Engine Assembly Marine Whole Original Chinese TS16949 CertifiCatere

    Ask Lasest Price
    Brand Name : JINGTE
    Model Number : R6160
    Price : competitive price
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 200 piece per month
    Delivery Time : 15day
    • Product Details
    • Company Profile

    R6160 Diesel Engine Assembly Marine Whole Original Chinese TS16949 CertifiCatere

    Whole Original Chinese Engine R6160 Marine Diesel Engine Assembly


    1. Engine assembly: MARINE engine assembly


    2. Material of Marine R6160 engine assembly: Steel for Ship engine


    3. Adjustment: Setting and adjustment of engine


    4. Applicable Area: Marine engine, boat engine etc.

    NameChinese R6160 R6170 WP4 WP10 WP12 WP13 WD615 WD618 Engine
    PackingWooden packing
    Delivery1-3 Working Days
    Fuel typeDiesel
    AppliCatererionChinese Marine Engine

    5. Features of Marine R6160 engine assembly:

    ItemUnitengine type
    R6160
    ZC223-5
    R6160
    ZC250-5
    R6160
    ZC275-5
    R6160
    ZC300-5
    R6160
    ZC326-5
    intake modeturbochargedturbocharged and intercooled
    number of cylinders6
    bore X stroke160×225
    displacementL27.14
    compression ratio14.5:1
    rated powerKW164184202220240
    rated speedr/min850850850850850
    min. fuel oil consumptiong/(KW.h)205
    fuel consumption @ rated powerg/(KW.h)≤218≤218≤213≤213≤210
    lub oil and fuel consumption ratiog/(KW.h)≤1.36
    cooling modesea and fresh water duel-circulation cooling system
    start modeelectric start/air/both
    net weightkg3400
    rotation direction of crankshaft (seen from the free end)clockwise
    dimensionlengthmm2644
    widthmm1134
    heightmm1768
    ItemUnitengine type
    R6160
    ZC223-1
    R6160
    ZC250-1
    R6160
    ZC275-1
    R6160
    ZC300-1
    R6160
    ZC350-1
    intake modeturbochargedturbocharged and intercooled
    number of cylinders6
    bore X stroke160×225
    displacementL27.14
    compression ratio14.5:1
    rated powerKW164184202220255
    rated speedr/min10001000100010001000
    min. fuel oil consumptiong/(KW.h)205
    fuel consumption @ rated powerg/(KW.h)≤216≤216≤216≤216≤216
    lub oil and fuel consumption ratiog/(KW.h)≤1.36
    cooling modesea and fresh water duel-circulation cooling system
    start modeelectric start/air
    net weightkg3400
    rotation direction of crankshaft (seen from the free end)counter clockwise
    dimensionlengthmm2644
    widthmm1134
    heightmm1768
    ItemUnitengine type
    R6160
    ZC279-1
    R6160
    ZC408-1
    R6160
    ZC450-1
    R6160
    ZC490-2
    intake modeturbocharged and intercooled
    number of cylinders6
    bore X stroke160×225
    displacementL27.14
    compression ratio14.5:1
    rated powerKW205300330360
    rated speedr/min1000100010001200
    min. fuel oil consumptiong/(KW.h)205
    fuel consumption @ rated powerg/(KW.h)≤210≤210≤210
    lub oil and fuel consumption ratiog/(KW.h)≤1.36
    cooling modesea and fresh water duel-circulation cooling system
    start modeelectric start/air
    net weightkg3400
    rotation direction of crankshaft (seen from the free end)counter clockwise
    dimensionlengthmm2644
    widthmm1134
    heightmm1768
    Type4 stroke,Dual-circulate water cool,inline,direct injectionCylinder No.6
    Broke/stroke160×225 mmDisplacement27.14L
    Mini.fuel consumption ratio205 g/kW·hLub-oil consumption ratio1.0 g/kW·h
    Starting methodAir/electrical startIdle speed500±50 r/min
    Fire sequence1-5-3-6-2-4 right engine/ 1-4-2-6-3-5 left engineSmoke sensity≤1.0 RB
    Noise≤114 dB(A)EmissionIMO TIER Ⅱ
    Crankshaft rotating direction(face to free end)Clockwise/unticlockwiseOverhual period12000 h

    6. Package: Wooden package+pallet


    7. Deliver time: Normally in stock

    Port: Tianjin, CN
